DESCRIPTION

Basic Info.

Model NO.	WL-12/WL-13/WL-15
Service Life	6-10 Years
Size	Small
Color	Red
Condition	New
Engine Type	Inline, Cooled Water, Four Stroke
Engine Rated Speed	2400(R/Min)
Steering	Mechanical Steering
Clutch	Dry Type Single Action Clutch
Hanging Shaft Rated Lifting Capacity	2980n
Farming Adjustment Methodsize	Height Adjustment
Rear Tyre	6.00-12/6.00-16/6.5-16
Front Tyre	4.00-10/4.00-12
Engine	Single-Cylinder/Horizonta/Water Cooled/ Four Strok
Wheel Base(mm)	1200
Rated Power	8.46kw/ 9.56kw/ 11.03kw
Mode	CF12nm/ CF13nm/ CF15nm
Dry Mass	460kg
Transmission Box	6f + 2r Shifts
Min Ground Clearance	200mm
Transport Package	Iron Frame(Iron Crate) or Metal Frame
Specification	2200*1100*1210
Trademark	Taihong
Origin	China
HS Code	8701100000
Production Capacity	1000 Set Per Month

Product Description

High Quality 12-15HP 2WD half belt driven Farm/Mini/Diesel/Small Garden/Agricultural Tractor
agricultural tractorfarm / mini tractor12-15hp tractor
Product Parameters

Main Technical data
Tractor model								WL-12/WL-13/WL-15
Type								2×2 wheel half belt drive
Rated traction								1800N
Tractor Size (mm)	Overall size							2200*1100*1210
	Wheel base							1200
	Wheel base					Front wheel		850(4.00-12)/ 840(4.00-10)
						Rear wheel		890(6.50-16)/880(6.00-12)
	Mini ground clearance(gearbox)							200
Turnning radius								2.2±0.2m
Theoretical Speed		Forward 1shift						2.1km/h
		Forward 2 shift						3.28km/h
		Forward 3shift						5.32km/h
		Forward4 shift						8.56km/h
		Forward 5shift						13.32km/h
		Forward 6shift						21.53km/h
		Reverseshift 1						1.62km/h
		Reverse shift 2						6.59km/h
Tractor Weight		Type						Hydraulic lifting
		Structural mass						460kg
Engine
Type		Single-cylinder/Horizonta/Water cooled/ four stroke/direct injection
Model		CF12NM/ CF13NM/ CF15NM
Rated power		8.46kw/ 9.56kw/ 11.03kw
Rated speed		2400r/min
Cylinder NO		1
Bore		92mm
Cooling method		Condensing
Starting method		Electric start
Electioric Equipment
Model							RFF-90 Permanent Magnet Alternator
Voltage(V)							12
Rated power(w)							90
Rated speed(r/min)							2400
Transmission System
Clutch							Two blade,dry type,joint
Transmission type							(3+1)×2 combined type
Differential device							Closed,symmetrical bevel gear
Brake system					Brake type		Hook type
					Operation method		Mechanical pedal
Walking and Steering System
Front axle							Unitary,unadjustable
Front tire size							4.00-10/4.00-12
Rear tire							6.00-12/6.00-16/6.5-16
Tire pressure(Kpa)							180Kpa
							Field operation 80-120Kpa
							Transport operation 140-200Kpa
Steering system				Steering type			Worm type/ worm roller type
				Operatio type			Mechnical
Working device
Model							Semi-split
Oil pump							Single piston/gear pump
Safty valve opening pressure							16±0.5MPa
Cylinder diameter/Piston stroke							63/150m
Pump fuel pump theory							5L/MIN
Hanging shaft rated lifting capacity							2980N
Rated lifting time							≤3S
Farming adjustment method							Height adjustment
Ground clearance of dragger							240mm
Electirc equipment
Battery							Lead acid battery 12V/45ah
Diesel engine type							Evaporation or condensation
Generator			Model				Permanent magnet flywheel generator
			Voltage/Power				14V/350W
Head light							12V/55W Double wire distance light
Turnlight							12V/8W

Quality control
Starting from the source,from casing parts to the whole process control,uality control on Spares and finished to keep quality and performance consistent.

About us
Weifang Taihong Tractor Co.,Ltd established in 1990, with coverage of 206677 square meters, is one of the most professional tractor manufacturer in China. With 20 years development, Taihong is capable of producing tractor from 25hp to 240hp and has a large market share at home and abroad. Taihong has its own foundry, casting, machinery processing center. Some parts are made by itself to realize the whole quality control from spare parts. The products are certified by ISO9001, SGS, CCC.
Our WorkshopOur CertuficationAgricultural Implements
Disc plough, disc harrow, cultivator, potato harvestor, mower, front end loader and pbackhoe, snowbrush, hay baler, planter etc.
Packing and DeliveryOur Service

Pre - Sale Service	1,Any questions about our machine will be answered as soon as possible within 24 hours.2,Optimum design and selection according to customer's requirements and environment
Sale Service	1,We are responsible for pre-factory inspection.2,Technical guidance on common problems3,Provide guidelines and videos on how to use them
After - Sale Service	1,Except for fragile parts, the whole machine is guaranteed for one year.2,Provide 24-hour technical support via e-mail/telephone

Our ClientsWhy choose us?

1	We are a manufacturer with our own factory. It's easier to control costs than a trading company. We can also give you a faster and more professional answer.
2	As a manufacturer, we can produce our own parts. In technology, we can give you more professional introduction and service.
3	We have professional technicians and production lines, and long-term mature production experience.
4	Our products have complete specifications and different sizes. We can also improve our products according to customers' requirements.
5	We enjoy a good reputation among customers in domestic and foreign markets. We hope that we can have long-term and pleasant cooperation.

FAQ
1. Q: Are you a factory or a trading company?We are a professional manufacturer of tractors. It has more than 20 years of experience.2. Q: Why did you choose us?A The tractor is of good quality and reasonable price.B Good service: Customers have questions to answer within 24 hours.C For all the machines we sell, we will provide a one-year warranty free of charge.3. Q: What should I do if I encounter problems in the use process?We are pleased to provide you with our support. We can shoot a video of the machine to demonstrate how to solve the problem and provide you with detailed solutions.4. Q: How is your after-sales service?
A: What's wrong with you, whether it's within the warranty period or not? Just give us an e-mail or video. Our engineers and I are very willing to solve this problem for you. We have not only high quality machines, but also good after-sales service.
Service and Warranty:
For main parts,warrnty period is one year from the BL date. During the warranty, if the problem is occuring, please send us problem desctriptions and photos for technical analysis, we will be acting immediately and give solution within 24 hours. From technical analysis,if the problem is because of make, craftsmanship and the manufacturing reason; the relative charges will be borne by seller; if the problem is caused by improper operation, the buyer will take the responsibility and bear the relative charges and seller will try his best provide and other possible support and assistance to solve the problem.
